Technical data:
Material: Stainless steel 304
Finish: Matte black
Lock: Metal lock and key
Capacity: Roll Ø 13 - 17 cm
Roll width: 13 - 21 cm
Core diameter: Min. 35 mm
Power supply: 4 LR20 alkaline batteries or 6V voltage, 5.5 / 2.1 mm tip
Additional features: Adjustable towel length 20 - 40 cm
Dispenser dimensions: Height 355 mm, width 295 mm, depth 190 mm
Carton dimensions 1 pc: Height 360 mm, width 300 mm, depth 195 mm
Dispenser weight: 4.5 kg
Carton weight 1 pc: 5 kg
Quantity in bulk carton: 2 pcs
Bulk carton dimensions: Height 400 mm, width 320 mm, depth 400 mm
Bulk carton weight: 10 kg
Bulk carton volume: 0.051 m³
Warranty: 2 years "door-to-door"
