Read | Description | Download |
---|---|---|
sa1003sjbl-2d-en.dwg (212.2 KB) | Automatic liquid soap and disinfectant dispenser 1l HIT black - CAD 2D drawing | |
sa1003sjbl-3d-en.dwg (102.2 KB) | Automatic liquid soap and disinfectant dispenser 1l HIT black - CAD 3D drawing | |
sa1003sjbl-inst-en.pdf (631.4 KB) | Automatic liquid soap and disinfectant dispenser 1l HIT black - Assembly and operation instructions |
Technical data:
Material: Stainless steel 304
Finish: Black
Capacity: 1 liter (1000 ml)
Control: Soap level control window in the dispenser
Lock: Metal lock and key
System: Non-drip valve
Dispensing method: Automatic (motion sensor)
Refilling: From a canister
Additional elements: Adapter (optional), plastic soap tank
Dispenser dimensions: Height 290 mm, width 100 mm, depth 90 mm
Carton dimensions 1 pc.: Height 295 mm, width 105 mm, depth 95 mm
Dispenser weight: 1 kg
Carton weight 1 pc.: 1.042 kg
Quantity in bulk carton: 12 pcs.
Bulk carton dimensions: Height 400 mm, width 340 mm, depth 360 mm
Bulk carton weight: 12.5 kg
Bulk carton volume: 0.049 m³
Power supply: 6 AA alkaline batteries or adapter (DC)
Warranty: 2 years "door-to-door"
For the motion sensor to work properly, the distance to the edge of the countertop or sink must be at least 150 mm
